| 標準仕様 |
| Dimensions：L×W×H |
838×1090×1610mm（excluding signal tower） |
| Weight |
36㎏ |
| Axes |
3（X,Y,Z） |
| Drive |
Servo motor |
| Valve motion |
90° rotary & left/right 45° tilting |
| Maximum valves |
2 |
| Installed valves |
SV70, SV91CD, SV51, SV35DA, SV91, SV97MS |
| Movement range（single-side valve） |
450×500×100mm *Can be applied to M-size board |
| Coating area (XY) |
370×400mm |
| Movement speed |
1-500mm/sec |
| Positioning accuracy |
±0.01mm |
| Conveyor |
Electrically adjustable type（width 50-510mm） |
| Conveying direction |
Left→Right |
| Pass line adjustment range |
880-965mm |
| Work height（maximum） |
100mm |
| Light |
Inspection UV light & LED lighting |
| Camera resolution |
12 million pixels |
| Camera functions |
Teaching, position correction, post-coating inspection |
| Air specifications |
φ8 hose, 0.6Mpa（maximum input pressure） |
| Power supply voltage |
AC200~240V（single phase） |
| Power consumption |
3.5A |
